Canisteo Motorized Dual Shades Pro
$309.99
Unit price per30-Day Price Guarantee
Shop now with confidence. If the price drops during our Black Friday sale within 30 days of your purchase, we'll refund the difference.
How To Measure Your Shades
Need help measuring? Visit our How to Measure guide for detailed instructions.
Start by measuring the depth of your window frame from the top where the brackets will be installed. lf the frame depth is under minimum depth or if there's an obstruction like a lever or crank, consider opting for an outside mount.
2. Measure Window Width
Take three horizontal measurements: at the top, middle, and bottom of your window frame, from left to right, should these measurements vary, select the smallest one as your window width. Do not make your own deductions. We will make all the necessary deductions based on the measurements you provide. Don’t add to the width to make up for any deductions that we will take. For more light coverage, choose an outside mount.
3. Measure Window Height
You’ll need to record three separate measurements, each from top to bottom. Measure the left, center, and right sides of window frame. If these measurements differ, use the longest measurement of the three as your window height.
Outside Mount
1. Measure Surface Area
Check the area above your window frame or molding to verify there's at least 2" of flat vertical space available for mounting the head rail. Mark the spot where you intend to install the top of your shades.
2. Measure Window Height
Starting from the mark you made (indicating the top), measure downward to the bottom of the window, For optimal light control and privacy, ensure there is a minimum overlap of 3".
3. Measure Window Width
Record the desired width of your shades by measuring horizontally from left to right. For standard shades, an overlap of at least 3" to 6" is suggested. For outdoor shades & cellular shades, aim for a minimum of 2" overlap. For roman shades, aim for a minimum of 5" overlap. lf wall obstructions are present,consider using extension brackets to allow the blinds to extend sufficiently clear of these impediments.
Measure Multi Shades in One Window
Helpful Tips for Measuring
Roller Shades | Zebra Shades | Dual Shades Plus: The width measurement provided is for the cassette size; The fabric is 1.2" smaller than the cassette measurement.
Zebra Shades: The width measurement provided is for the cassette size; The fabric is 1.2" smaller than the cassette measurement.
Woven Wood Shades | Cellular Shades: The width measurement provided is for the cassette size; The fabric is 1.2" smaller than the cassette measurement.
Outdoor Shades: The width measurement provided is for the cassette size; The fabric is 2 1/8" smaller than the cassette measurement.
Roman Shades: The width measurement provided is for the cassette size; The fabric is 1/8" smaller than the cassette measurement.
Why They Are Loved
-
Upgraded arched valance creates a cleaner, fully enclosed finished look
-
Flexible split dual roller structure supports extra-large custom window sizes
-
Independent fabric layers for customizable light and privacy
-
Versatile multi-power supply options
-
Practical modular build with flexible customization for your window
Customization Options
-
Versatile fabric & color choices
-
Front Shade Color (Distant from the window): Blackout Pure | White, Blackout Pure | Cream, Blackout Linen | White, Blackout Linen | Stone, Blackout Cozy | Smoke, Blackout Cozy | Midnight, Blackout Neat | Medium Grey — all our roller shade blackout fabrics are available.
-
Back Shade Color (Near the window): Light Filtering PVC-Free | White, Light Filtering PVC-Free | Pearl, Light Filtering Dusk | Veil, Light Filtering Dusk | Shadow, Room Darkening Cozy | Biscuit, Room Darkening Linen | White, Room Darkening Linen | Sand — all our roller shade light filtering & room darkening fabrics are available.
-
Motor options for different smart setups
-
Choose your preferred power source for your installation needs
-
Mounting notes for vertical windows
-
Valance & Bottom Rail Style
-
Motor Side Selection
-
Remote control selection
Designed for Modern Living
The Canisteo Difference
Choose Your Motor→
Control your shades alongside other compatible smart devices and create routines, scenes, and automations that fit your daily life.
1. Standard Motor
Operated exclusively via remote control. Standard Motor + Smart hub can also achieve smart control.
2. Zigbee Motor
Ideal for users with existing Zigbee smart home systems or Alexa devices with built-in hubs, looking for reliable and responsive automation of their window treatments.
3. Z-Wave Motor
Ideal for Z-Wave smart home setups, allowing your shades to become part of a broader connected-home automation system.
4. Matter over Thread Motor
Our most advanced smart home option. Matter over Thread provides fast, reliable, and secure communication with compatible platforms including Apple Home, Amazon Alexa, Google Home, Samsung SmartThings, and Home Assistant.
Remote Control
All Canisteo remotes require 2 AAA batteries.
1-Channel Remote
Controls one shade independently.
Recommended for a single shade.
5-Channel Remote
Channel 0: Controls all paired shades simultaneously
Channels 1–5: Control individual shades by channel
Ideal for multiple shades in the same room.
15-Channel Remote
Channel 0: Controls all paired shades simultaneously
Channels 1–15: Control individual shades by channel
Ideal for larger rooms or multiple shades throughout your home.
Power Options
1. Lithium Battery
Rechargeable, cordless, and easy to install.
Includes a 118" USB-C charging cable. A charging adapter is not included; use a standard USB-C power adapter, power bank, or compatible Canisteo Solar Panel.
Depending on shade size and usage, a full charge typically provides approximately 4–6 months of operation.
Best for easy installation without visible power cords.
2. Hardwired DC 12V
Ideal for a clean, permanent power setup.
Includes:
- 11.8" motor cable
- 7.8" extension cable
- DC 12V power supply
Recommended when a nearby power source is available.
3. Hardwired AC 110–230V
Designed for direct connection to a standard power outlet.
Includes a 78" power cord with plug.
Need a cord without a plug? Please leave a note with your order or contact us before purchasing.
Ideal for permanent installations with continuous power.
We highly value all our customers and prioritize delivering our merchandise to them swiftly.
Order Processing Time
As soon as you place your order, we begin customizing your shades to ensure rapid delivery. Production and packaging typically require 2-10 business days. Please note that our manufacture operates during standard business hours from Monday to Friday, excluding holidays.
Delivery Time
We provide free shipping across the US and internationally using UPS, FedEx, and DHL Express. Once your order leaves our warehouse, delivery usually takes between 3 to 18 business days, depending on the destination.
Shipping Costs
We offer free shipping to the USA and worldwide via UPS, FedEx, DHL, and USPS.
Return & Refund Policy
For custom products, Canisteo does not accept returns, but if the fault is from the Canisteo, we provide refunds or remake the products.
Order Cancellation
If you reach out to us soon after making your purchase, we can cancel the order and fully refund your money. However, as all orders are custom-made, cancellation is not possible once production has begun.
About Taxes
Occasionally, orders might incur customs fees charged by your government, not our website. Unfortunately, we cannot control these charges and they must be paid by you. We regret any inconvenience this may cause. For more details on customs fees, duties, and taxes, please consult your local customs office.
Unreceived Items
If you've placed an order but haven't received it, despite the tracking status indicating it has been delivered, you should contact the carrier to locate your package. We do not have control over the package once it is with the carrier. However, if you continue to face issues, please reach out to us at support@canisteoblinds.com.
Product specifications
IM*:Inside Mount
Width Range
28"~98"
Height Range
28"~118"
Depth Range
4 3/16"(10.7cm)
(IM)Minimum Depth*
4 3/16"(10.7cm)
Sound Level
36~55dB (AC hardwired starts at 44dB)
Motor Torque
Up to 20Nm (12V DC Hardwired: Max 10Nm)
Working Temp
-10~55℃
Battery Life
4~6 months per full charge
Warranty
Free 2-Years Warranty
SKU
CNST-DL-Pro
FAQs
